PRINTING

Print Technology:Fused Deposition Modeling

Build Volume:600*600*600 mm

Number of Nozzles:Dual

Resolution:0.05mm

Layer Resolution: 0.05mm

Filament Diameter: 1.75 mm

Filament Compatibility: PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA, PEEK, etc.

Nozzle Diameter: 0.4mm (0.3, 0.5, 0.6, 0.8, 1.0mm)

TEMPERATURE

Max. Nozzle Temperature: 420°C

Max. Bed Temperature: 100°C

SPEED

Best Printing speed: 45mm/s

Max. Printing speed: 120mm/s

Max. traveling speed: 120mm/s

MECHANICAL

Construction: Power-Coated Steel, Aluminum Casting for Motion Components, POM

Build Plate: Microcrystalline Ceramic Panel

Build Plate Leveling: Factory Leveled, Adjust Manually

Extruder: Geared motor (1:10 rate)

X Y Positioning Precision: 5.08 Microns

Z Positioning Precision: 1.25 Microns

ELECTRICAL

Power Requirements: 100-240V, 50-60Hz

Max. Power: 1000W

Screen: 4.3" Touch Screen

Connectivity: USB

SOFTWARE

Software Bundle: CreatWare Multi-language

Supported File Types: STL, OBJ, AMF

Operating Systems: Windows (7,8,10)   Mac OS X

SPECIAL FUNCTION

Outage Restored: Sava data when power is off

Filament Detection: Pause printing when filament run out

Automatic Shut-down: Turn off the power automatically when printing is complete

SIZE & WEIGHT

Product Dimensions & Weight: 915*845*1085mm 125Kg

Packing Size & Weight: 1000*1030*1360mm 190Kg (Pallet)
